Product Features
· High power PCT red copper leadframe package
· ESD Level; Class 2
· High resistance to vulcanization, High temperature resistance
· Surface mounting technology (SMT) support
Model No | LC-2835A05CA | LC-2835A05EA | LC-2835A05SA | LC-2835A05WA | LC-2835A05LA |
CCT(k) | 2700K | 3000K | 4000K | 6500K | 10000K |
Power | 0.5W | ||||
IF(mA) | 150 | ||||
Voltage(v) | 3V | ||||
Flux(Lm) | 55-60 | 60-70 | 60-80 | 60-83 | 55-60 |
Efficiency(Lm/W) | 110-130 | 130-150 | 130-180 | 130-180 | 110-130 |
| Ra | 80/90 | ||||
Model No | LC-2835A05CA | LC-2835A05EA | LC-2835A05SA | LC-2835A05WA | LC-2835A05LA |
CCT(k) | 2700K | 3000K | 4000K | 6500K | 10000K |
Power | 0.5W | ||||
IF(mA) | 60 | ||||
Voltage(v) | 9V | ||||
Flux(Lm) | 60-76 | 60-80 | 60-95 | 60-95 | 60-70 |
Efficiency(Lm/W) | 105-125 | 105-145 | 100-178 | 100-178 | 100-120 |
| Ra | 80/90 | ||||
Model No | LC-2835A05CA | LC-2835A05EA | LC-2835A05SA | LC-2835A05WA | LC-2835A05LA |
CCT(k) | 2700K | 3000K | 4000K | 6500K | 10000K |
Power | 0.5W | ||||
IF(mA) | 30 | ||||
Voltage(v) | 18V | ||||
Flux(Lm) | 60-70 | 60-75 | 70-80 | 70-85 | 55-65 |
Efficiency(Lm/W) | 100-125 | 100-130 | 100-140 | 100-145 | 100-120 |
| Ra | 80/90 | ||||
