Detail
Product Features
· Support high power T8 glass tube (30W)
· PCT Copper leadframe encapsulation，high reliability
· ESD Level; Class 2
· High resistance to vulcanization, High temperature resistance
· Surface mounting technology (SMT) support
· Ultra-high luminous efficacy,ultra-high luminance
High light efficiency
Model No | LC-2835A02EA | LC-2835A02SA | LC-2835A02WA |
| CCT(k) | 3000K | 4000K | 5000K |
| Power | 0.2W | ||
| IF(mA) | 60 | ||
| Voltage(v) | 2.7V | ||
| Flux(Lm) | 34-36 | 36-38 | 38-40 |
| Efficiency(Lm/W) | 210-225 | 225-237 | 235-250 |
| Ra | 80 | ||
Model No | LC-2835A02EA | LC-2835A02SA | LC-2835A02WA | LC-2835A02LA |
| CCT(k) | 3000K | 4000K | 5000K | 10000K |
| Power | 0.2W | |||
| IF(mA) | 60 | |||
| Voltage(v) | 2.7V | |||
| Flux(Lm) | 34-40 | 36-40 | 38-45 | 34-40 |
| Efficiency(Lm/W) | 188-245 | 200-250 | 211-270 | 188-245 |
| Ra | 70 | |||
Regular
Model No | LC-2835A02EA | LC-2835A02SA | LC-2835A02WA | LC-2835A02LA |
| CCT(k) | 3000K | 4000K | 6500K | 10000K |
| Power | 0.2W | |||
| IF(mA) | 60 | |||
| Voltage(v) | 2.7-3.2V | |||
| Flux(Lm) | 24-33 | 24-34 | 24-34 | 24-33 |
| Efficiency(Lm/W) | 120-195 | 120-200 | 120-200 | 120-195 |
| Ra | 80 | |||
